Specifications
Android Operating System( Option 1)
| CPU | RK3399, Dual-core Cortex-A72 + Quad core Cortex-A53, MAX 1.8GHz | |||||||||||||
| GPU | ARM Mali-T864 | |||||||||||||
| RAM | 4GB | |||||||||||||
| Internal memory | 64GB EMMC | |||||||||||||
| Network | LAN 10/100M Ethernet Port, WiFi 802.11b/g/n, 3G/4G SIM slot is optional | |||||||||||||
| Interface | USB ports*2 | |||||||||||||
| Operation system | Android 7.1/ Android 8.1 | |||||||||||||
Android Operating System( Option 2)
| CPU | RK3288, Quad-core Cortex-A17, MAX 1.8GHz | |||||||||||||
| GPU | ARM Mali-T764 | |||||||||||||
| RAM | 2GB/4GB | |||||||||||||
| Internal memory | 16GB/32GB/64GB EMMC | |||||||||||||
| Network | LAN 10/100M Ethernet Port, WiFi 802.11b/g/n, 3G/4G SIM slot is optional | |||||||||||||
| Interface | USB ports*2 | |||||||||||||
| Operation system | Android 7.1/ Android 8.1/ Android 9/ Android 10 | |||||||||||||
Free Remote Content Management Software(For Android Only)
| Editing Playlist, timing, playback | ||||||||||||||
| Edit Multi Zones Play different contents | ||||||||||||||
| One Video/image splicing to multiple screens by software, no need for extra controller/matrix/HDMI splitter | ||||||||||||||
| Support live stream, URL, Youtube Video, PDF, WORD, TXT, etc | ||||||||||||||
| Remote Management by mobile, PC thru wifi/LAN network | ||||||||||||||
| Support 4K high-resolution videos, Max uploading video 2GB, Max uploading image 20MB | ||||||||||||||
| Support Simple USB sticker plug-play looping images/videos | ||||||||||||||
| Cloud base software is supported | ||||||||||||||
| Free of charge |
Display
| Panel Size | 43″ High TNI 105℃ Outdoor Digital Signage LCD | |||||||||||||
| Resolution | 1920*1080 | |||||||||||||
| LCD Manufacturer | BOE( Industrial grade panel, wide working temperature-20~ +60℃) | |||||||||||||
| Viewing angle | 89/89/89/89(L/R/U/D) | |||||||||||||
| Contrast ratio | 1200:1 | |||||||||||||
| Brightness | 2500nits | |||||||||||||
| Aspect Ratio | 16:9 | |||||||||||||
| Active Area | 529(W)×940(H) mm | |||||||||||||
| Operational Life | 50K hours | |||||||||||||
| Grey to Grey Response Time (ms) | 6ms | |||||||||||||
Battery
| Battery Technology | lithium-ion battery | |||||||||||||
| Charging Time | 7 hrs | |||||||||||||
| Working Time | 8~10 hrs | |||||||||||||
| Battery Capacity | 57Ah | |||||||||||||
| Power Supply | 25.2V | |||||||||||||
| Power Consumption | 200W(Max) | |||||||||||||
| Battery Status Digital LCD Indicator | Incl | |||||||||||||
Environment
| Operating Environment | Fully Outdoor | |||||||||||||
| Operating Temp. | -20℃ ～+60℃(when the battery is charging 0℃~45℃） | |||||||||||||
| Storage Temp. | -20℃ ～+60℃(Built-in battery, recommend long-term storage temperature from -20℃~25℃） | |||||||||||||
| Operating Humidity | 10% ~ 80% | |||||||||||||
| Storage Humidity | 5% ~ 95% | |||||||||||||
Others
| Speaker | 8Ω 10W*2 | |||||||||||||
| Accessories | Remote Control, Charging cable | |||||||||||||
| Wheels Locker | Support | |||||||||||||
| Battery Status Digital Indicator | Show battery remaining, charging time | |||||||||||||
